Exam notes

Lexical analysis

• McNaughton-Thompson-Yamada algorithm: regex -> NFA
• Subset Construction: group equivalent states ($\epsilon$-closures), transition table with $\text{move}(S,c)$, NFA -> DFA
• Systematic minimization:
  1. Start with two groups: all non-final states and all final states.
  2. Within a group, check pairs for equivalence. If found, these are separated into their own group.
  3. In the end, the equivalence groups may be merged to create a minimized DFA

Syntax analysis

LL(1) tables. (x, y) = (term. + $, non-term.). Enter X -> a at (X, s) if s is in FIRST(a). If nullable, also enter X -> e at (X, t) where t is in FOLLOW(a).

LR(0) automaton. Maybe add root. Add prods where dot is before non-term.

LR(0) table. (x, y) = (Automaton state, term. + $ | non-term.) Items: shift(state), reduce(prod) or goto(state).

SLR(0): Only reduce(prod) if column terminal is in FOLLOW.

LALR: "Merge states that are similar except for the lookahead"

Tabulate derivation: Cols: Stack, Input, Action. Either Output/Match or Shift/Reduce

Left factoring shortens the distance to the next nonterminal

E.g. from

• A $\rightarrow$ abcdef | abcxyz

To

• A $\rightarrow$ abcA'
• A' $\rightarrow$ def | xyz

Left recursion elimination shifts a nonterminal to the right

E.g. from

• A $\rightarrow$ A a | a

To

• A $\rightarrow$ a A'
• A' $\rightarrow$ a A' | $\epsilon$

A symbol table may store names, types and memory location (e.g. function address).

L-attributed (top-down) grammars allow synthesized attributes, and inheritance from the left. In S-attribution (bottom-up), all attributes are synthesized.

Intermediate representation

x = &y OP *z
Label:
goto Label
if x OP y goto Label
param x
call Label
return a[i]

Data flow analysis

A node X dominates a node Y if every path to Y must go through X. Every node dominates itself.

A partial order (P,⊑) contains a set of things P and a relation ⊑. The relation is reflexive, anti-symmetric and transitive. A partial order is a lattive if all subsets have a g.l.b. and l.u.b.

MOP = MFP when the transfer function is distributive with regard to the meet operation. E.g. the they only depend on set union and intersection. (MFP) F(x U y) = F(x) U F(y) (MOP)

A live variable is one which holds a value that may still be used at a later point

* either non-const, number or T (const)

Forward: out[I] = { in[I] – kill(I) } ⋃ gen(I) Backward: in[I] = { out[I] - kill(I) } ⋃ gen(I)

Optimization

• Function inlining
• Function cloning (specialization)
  • Optimize for certain inputs or environments
• Constant folding
  • Compile-time calculations of expressions with known values
• Constant propagation
  • Constant variable replaced by value
• Unreachable/dead code elimination
  • x = 1; x = 2; or if false:
• Loop-invariant code motion
• Common sub-expression elimination
• Strength reduction
  • Replace expensive operations with cheaper ones, e.g. replace multiplication by addition
• Loop unrolling

Run-time environment and Code generation

C is statically typed but not type safe. Javascript is dynamically typed, but type safe. (Crashes on type error)

Dynamic dispatch: to select implementation of a polymorphic operation to call at run time. Given a variable of known type, the dispatch vector provides the correct function address. Interfaces are constraints on the dispatch vector layout.

return value: RAX,
parameters: RDI, RSI, RDX, RCX, R8, R9, (stack)

x86 Example

.globl main
.section .data
hello:
 .string "Hello, world! %ld\n"
.section .text
main:
 pushq %rbp
 movq %rsp, %rbp
 movq $42, %rsi
 movq $hello, %rdi
 call printf
 leave
 ret

An activation record

..
Next call's local variables
My frame ptr.
------------------- <
Return address
Arguments
(Intermediate data)
Local variables
Caller's frame ptr.
------------------- <
Return address
Arguments
..

Tools

// scanner.l (lex)

%{
// Define tokens
%}

%option

WHITESPACE [\ \t\v\r\n]
COMMENT \/\/[^\n]+

%%
{WHITESPACE}+           { /* Eliminate whitespace */ }
{COMMENT}               { /* Eliminate comments */ }
func                    { return FUNC; }
[0-9]+                  { return NUMBER; }
  /* Unknown chars get returned as single char tokens */
.                       { return yytext[0]; }
%%

// parser.y (yacc)

%{
/* State variables from the flex generated scanner */
extern int yylineno; // The line currently being read
extern char yytext[]; // The text of the last consumed lexeme
/* The main flex driver function used by the parser */
int yylex ( void );

%}

%token FUNC PRINT RETURN BREAK IF THEN ELSE WHILE FOR IN DO OPENBLOCK CLOSEBLOCK
%token VAR NUMBER IDENTIFIER STRING

%left '+' '-'
%left '*' '/'
%right UMINUS

%nonassoc IF THEN
%nonassoc ELSE

%%
program :
      global_list { root = node_init (PROGRAM, NULL, $1 ); }
    ;
identifier: IDENTIFIER { $ = node_init(IDENTIFIER_DATA, strdup(yytext) ); }
%%
